RF Bands Wide-band operation 4.9 to 6.05 GHz (Allowable frequencies and bands are dictated by individual country
regulations)
Channel sizes 5, 10, 15, 20, 30, 40, and 45 MHz channels
Channel sizes depend on individual country regulations
Spectral Efficiency 10 bps/Hz maximum
Channel selection By Dynamic Spectrum Optimization or manual intervention
Automatic selection on start-up and continual self-optimization to avoid interference
Maximum Transmit Power Up to 27 dBm
System Gain Up to 164 dB with Integrated antenna
Modulation /
Error Correction
Fast Preemptive Adaptive Modulation featuring 13 modulation / FEC coding levels ranging from BPSK to 256 QAM
dual payload MIMO
Duplex Scheme Time Division Duplex (TDD)
Adaptive or fixed transmit/receive duty cycles
Split frequency operation allows separate transmit and receive frequencies where allowed by regulation.
Optional TDD synchronization using PTP-SYNC Module
Antenna Integrated Flat panel: 23 dBi
Connectorized: operate with a selection of separately-purchased single and dual polarity
antennas through 2 x N-type female connectors
Range Up to 155 miles (250 km)
Security FIPS-197 compliant 128/256-bit AES Encryption (optional) HTTPS and SNMPv3 Identity-based user accounts
Configurable password rules
Event logging and management; optional logging via syslog Disaster recovery and vulnerability
management
